Monolith XL
Energy and communication in a new dimension.
Monolith XL is not just a charging station, it is a statement of power and innovation. Ideal for large commercial applications, it offers unmatched performance and commanding presence.
from the inside out.
01 Overview
Sky Blue
Free-standing floor installation
The 55-inch screen becomes part
of the charging infrastructure.
With up to 44 kW of power, a built-in 55-inch advertising screen and a 7-inch touchscreen, the Monolith XL goes beyond what a charger is expected to be. Stable floor mounting, solid construction and pioneering technology make it thoroughly dependable. Choose the Monolith XL and put your business at the center of electric mobility.
- Maximum power
- 44kW
- Charging outputs
- 02outputs
- Protection
- IP55enclosure
- Net weight
- 75kg
02 Design
Energy and communication.
Fully under control.
Monolith XL integrates two-vehicle charging and digital communication into one architectural presence for high-traffic areas.
03 Technology
Designed for
continuous public use.
- 01
44 kW / Mode 3
Three-phase supply, two connection points and a fixed 5 m cable.
- 02
Large-scale display
A 55-inch advertising screen and a separate 7-inch touchscreen.
- 03
Access and networking
Autostart, code or RFID, OCPP 1.6 and optional Wi‑Fi, Bluetooth or 4G LTE.
- 04
Floor-standing metal unit
Sheet metal enclosure, IP55 protection and Sky Blue finish.
04 Power and control
44kW.
Exactly where it is needed.
Power, communication and safety work as one system, matched to the needs of your installation.
05 Specifications
Everything you need.
Nothing you don't.
The Monolith XL's technical data, organized for quick reading and accurate assessment.
01ElectricalPower delivery
- Charging capability
- 44 kW
- Charging mode
- Mode 3
- Number of connectors
- 2 X
- Connector type
- Type 1 (SAE J1772), Type 2 (IEC 62196-2), NACS
- Fixed cable length
- 5 meters
- Power connection
- 3-phase, 400/480 V AC, 32 A / 32 A * 2, 50-60 Hz
- Energy metering
- Optional MID Meter
- Identification method
- Autostart / Password / RFID card
- Display
- 55-inch Advertising Screen and 7-inch Touch Screen
02ConnectivityNetwork & control
- Wireless connection
- Wi-Fi / Bluetooth 4.0 (Optional)
- Mobile network
- 4G LTE (EU) (Optional)
- Serial port
- RS485 interface for dynamic load balancing and solar integration
- Protocol
- OCPP 1.6
- Positioning
- GPS (Optional) / Wi-Fi
- Maximum altitude
- +2000m
03SafetyProtection & compliance
- Earth leakage detection
- 6 mA DC CCID
- Operating humidity
- Max. 95% non-condensing
- Enclosure protection rating
- IP55
- Fire resistance
- UL94V-0
- Certification
- CE / US
- Operating temperature
- -20°C to +50°C
- Compliance
- UL2231, UL2594, FCC part15, IEC 61851-1, IEC 61851-21-2, CSA C22.2 No.280-13
04ConstructionPhysical system
- Height
- 1,965 mm
- Depth
- 229 mm
- Width
- 1,055 mm
- Enclosure material
- Sheet Metal
- Net weight
- 75 kg
- Gross weight
- 120 kg
- Installation method
- Floor standing all-in-one stand-alone unit
- Color
- Sky Blue
06 Your own installation
Monolith XL,where you need it.
Talk to the Hyperinso team about siting, power, connectivity and the management of your own installation.
Request a proposal for the Monolith XL
